Itel 6kW 48V Hybrid Solar Inverter (IPV-6K48U)
The Sunergyx 6kW 48V Hybrid Inverter is a high-performance solar energy solution designed to deliver reliable and efficient power for residential and commercial solar systems. With advanced MPPT technology, strong overload capacity, and intelligent cooling, this inverter ensures maximum energy utilization and long-term durability even in demanding environments.
Key Features
High Conversion Efficiency
The inverter delivers up to 99.9% MPPT tracking efficiency and 93% battery mode conversion efficiency, ensuring optimal energy harvesting from your solar panels.
Powerful 6kW Output
Provides 6000W / 6000VA rated AC output power, making it ideal for running household appliances, office equipment, and small commercial loads.
Wide Solar Input Range
Supports up to 6000W PV input power with a maximum DC input voltage of 500V and MPPT voltage range of 85V–450V, allowing flexible solar panel configurations.
Strong Overload Capacity
Designed to handle heavy loads with surge power up to 12000VA and overload tolerance of 150%–200% for short durations, making it suitable for starting motors up to 5HP.
Advanced Battery Compatibility
Compatible with Lead-acid, Lithium-ion, and user-defined battery types with a 48V battery system, offering flexibility for different energy storage solutions.
Fast Switching Technology
With a 10ms switch time, the inverter ensures uninterrupted power supply during grid outages.
Smart Cooling System
Equipped with intelligent fan cooling, maintaining optimal performance and protecting internal components from overheating.
Smart Load Management
Supports smart load control using an external contactor, enabling efficient energy distribution to essential loads.
Parallel Operation Capability
Supports up to 12 units in parallel, allowing system expansion for higher power requirements.
Generator Compatibility
Fully compatible with diesel generators using external ATS, ensuring continuous power availability in off-grid or hybrid systems.
Safety & Protection
The inverter includes multiple safety protections to ensure system reliability and equipment safety:
- Overload protection
- Short circuit protection
- Over temperature protection
- Surge protection (DC Type III / AC Type III)
- IP54 ingress protection for dust and moisture resistance
Technical Specifications
- Rated Output Power: 6000W / 6000VA
- Nominal Output Voltage: 220 / 230 / 240 VAC
- Output Frequency: 50Hz / 60Hz
- Maximum PV Input Power: 6000W
- Maximum DC Input Voltage: 500V
- MPPT Voltage Range: 85V – 450V
- Maximum Charging Current: 120A
- Maximum Battery Discharging Current: 130A
- Battery Voltage: 48V
- Operating Temperature: -10°C to +55°C
- Noise Level: ≤60dB
- Dimensions: 120 × 346.6 × 444.7 mm
- Net Weight: 15 kg
Communication & Monitoring
The inverter supports multiple communication interfaces for smart monitoring and system management:
- WiFi
- RS485 (BMS communication)
- RS232
- Dry Contact
Warranty
- 3 Years Replacement Warranty
- 5 Years Service Warranty
